Standing Rigging Tensions

2020-09-24 Loos Gauge Readings

Forestay Forward Lowers Uppers Aft Lowers Backstay Notes
1/4" 6900# 3/16" # 1/4" 6900# 3/16" # 1/4" 6900#
Constance #262 Roller P, S P, S P, S
Cookin' 21 08P, 06S 14P, 14S 04P, 04S 14
Latika #11 32 14P, 13S 13P, 16S 07P, 04S 26
Laughing Gull #197 31 12P, 07S 30P, 29S 04P, 04S 31
Skybird #550 27 17P, 21S 32P, 32S 14P, 12S 23
Solstice #501 Roller 14P, 09S 17P, 18S 08P, 09S 18
Sookie #221 Roller 20P, 20S 33P, 33S 04P, 04S 28
Windswept #562 37 27P, 22S 33P, 37S 15P, 14S 31

Constance Standing Rigging Tensions

Forward Lowers Uppers Aft Lowers Backstay Notes
7/32" 5450# 1/4" 6900# 7/32" 5450# 1/4" 6900#
2024-07-25 27P, 27S 34P, 34S 04P, 04S ??
2024-04-11 21P, 24S 34P, 34S 04P, 04S ??
2024-02-11 27P, 27S 32P, 34S 06P, 04S 19 RF718 set to 3 on the scale. On the hard. Listing to port.
2023-10-13 28P, 27S 34P, 34S 05P, 04S 19 RF718 set to 3 on the scale.
2023-05-10 27P, 28S 34P, 34S 04P, 04S 22 RF718 set to 3 on the scale.
2023-05-02 23P, 21S 30P, 30S 05P, 05S 25 RF718 set to 3 on the scale.
2023-04-29 20P, 20S 30P, 30S 06P, 04S 25 RF718 set to 3 on the scale.
2023-04-29 20P, 20S 30P, 30S 06P, 04S 25 RF718 set to 3 on the scale.
2021-10-08 22P, 23S 29P, 30S 05P, 05S 25 RF718 set to 3 on the scale.
2021-03-23 27P, 27S 30P, 30S 05P, 05S 19 After installing RF718.
2021-03-11 29P, 29S 31P, 31S 10P, 10S 19
2020-07-08 27P, 26S 29P, 30S 10P, 12S 19
2020-06-12 27P, 27S 29P, 30S 11P, 12S 19 Tightened new standing rigging after AYC WNR 20 knot sail.
2020-06-10 20P, 20S Measured after AYC WNR race with 20 knots of wind.
2020-05-21 24P, 25S 29P, 29S ??P, ??S 20 Tuned new standing rigging.
2020-01-22 26P, 25S 26P, 26S 08P, 09S 19
2019-06-07 24P, 25S 27P, 28S 06P, 08S 21
2018-09-04 27P, 26S 28P, 29S 09P, 10S 22
2018-07-11 24P, 24S 27P, 28S 09P, 10S 25
2018-05-10 24P, 23S 24P, 26S 06P, 07S 24
2017-11-29 24P, 23S 25P, 27S 07P, 08S 28
2017-08-18 25P, 25S 35P, 25S ??P, ??S 25
2017-05-22 29P, 27S 36P, 36S 13P, 14S 20
2017-05-03 30P, 27S 37P, 36S 13P, 14S 20
2017-04-24 30P, 29S 37P, 37S 13P, 15S 20
2016-12-11 24P, 21S 24P, 26S 07P, 07S 29
2015-11-15 24P, 22S 24P, 26S 09P, 09S 29
2015-05-17 24P, 22S 24P, 26S 09P, 09S 29
